FrameOSPimoroni Inky pHAT 2.13" black/white
212×104 black & white e-ink HAT for FrameOS - specs, setup and driver details.
Official Pimoroni store
Official store page for this device.
- Vendor
- Pimoroni
- Model
- Inky pHAT 2.13" black/white
- Technology
- E-ink
- Colors
- Black / White
- Resolution
- 212×104 px
- Size
- 2.13″ diagonal
- Interface
- SPI HAT
- Platforms
- Raspberry Pi
- Status
- 🟡 Should work
- FrameOS driver
pimoroni.inky_phat_black
Part of the FrameOS device database. Spotted an error, or tested this panel? Edit this page on GitHub - it's a markdown file.
The Pimoroni Inky pHAT 2.13" black/white is a 2.13″ e-ink panel with a resolution of 212×104 pixels showing black and white. Two-tone e-ink has the fastest refresh of any e-paper type - a full update takes only a couple of seconds - and the high contrast works great for text, dashboards and dithered photos. Pimoroni's boards are the easiest e-ink hardware to start with: panel and driver electronics come as one unit that plugs straight onto the Pi's GPIO header - no soldering, no separate driver board.
How it works
FrameOS ships a native Nim driver
(pimoroni.inky_phat_black) compiled straight into the binary that runs on your Raspberry Pi - no Python, no
vendor libraries. Each render pass draws your scene into a full-color image,
dithers it to the panel's palette, and pushes the result to the display over SPI.
Setup
- Plug the board onto the Pi's GPIO header.
- Add a frame in the FrameOS backend and select the Pimoroni Inky pHAT - 2.13" black/white driver.
- Save & deploy. The panel blinks through a refresh cycle and shows your scene.
Status
🟡 Should work, not yet confirmed on real hardware. The driver shares its controller logic with panels that are confirmed working. If you have this display, report your results with a photo and we'll mark it confirmed.
